Raing 额定: DC 30V 50mA

规格详情说明：

ELECTRICAL (电气特性):

(接触电阻) INITIAL CONTACT RESISTANCE: 50mΩ Max.

(操作力量) OPERATION FORCE: 400gf±100gf

(绝缘电阻) INSULATION RESISTANCE: 100MΩ Min. 250VDC

(电气寿命) ENDURANCE: 10,000 CYCLES

(耐电压) WITHSTAND VOLTAGE: AC 500V  rms(50-60Hz)FOR  1  MIN  TRIP CURRENT:0.5mA

(使用温度范围) PRACTICAL TEMPERATURE RANCE: -16℃～+60℃

(耐焊性试验) RESISTANCE TO SOLDERING HEAT TEST:

    *SOLDERING IRON METHOD:BIT TEMPERATURE 350±10℃ APPLICATION TIME OF SOLDERING IRON3±0.5SEC

     HOWEVER EXCESSIVE PRESSURE SHALL NOT BE APPLIED TO THE TERMINAL.

    *手焊接的时候温度控制在 350±10℃,时间为 3±0.5 秒,但不能在排脚上施加异常压力。

(耐冷试验) COLD TEST:

     *THE SWITCH SHALL BE STORED AT A TEMPERATURE OF -25±3℃ FOR 96 HOURS.THEN THE SWITCH SHALL BE MAINTAINED

       AT STANDARD ATMOSPHERIC CONDITIONS FOR 1 HOUR AFTER WHICH MEASUREMENT SHALL BE MADE.

     *放置在温度-25±3℃中 96 小时后,再将放置在常温常濕的环境中 1 小时后进行测试.

(耐热试验) HEAT TEST:

     *THE SWITCH SHALL BE STORED AT ATEMPERATURE OF 70±2℃ FOR 96 HOURS.THEN THE SWITCH SHALL

       BE MAINTAINED ATSTANDARD ATMOSPHERIC CONDITIONS FOR 1 HOUR AFTER WHICH MEASUREMENT SHALL BE MADE.

     *放置在温度 70±2℃中测试 96 小时后,再将放置在常温常濕的环境中 1 小时后进行测试.
